CPE structure for IEEE 802.22 MAC. More...

#include <802_22.h>

Collaboration diagram for stru_802_22_CPE_MAC:

[legend]

Data Fields
NETSIM_ID	nBSID

NETSIM_ID	nBSInterface

unsigned int	nSID:9
	Unique station idetifier.

int	nDSXRequestRetries
	3 fixed

int	nDSXResponseReties
	3 fixed

double	T7
	Wait for DSA/DSC/DSD Response timeout. Max 1 sec.

double	T8
	Wait for DSA/DSC Acknowledge timeout. Max 300 ms.

double	T14
	Wait for DSx-RSP/DSX-RVD Timeout. Max 200 ms.

double	T16
	Wait for bandwidth request grant. Min 10 ms.

double	T29
	Wait for BLM-ACK timeout. Range 10-300 ms.

int	nBLM_REPRetries
	Number of retries allowed for sending BLMREP. Default 3.

struct stru_802_22_CPE_BWRequestInfo *	BWRequestInfo

NetSim_PACKET *	pstruQueuedPacketList [MAX_FID]

CR_SERVICE *	pstruServiceParameter

NetSim_PACKET *	pstruUSBurst

NetSim_PACKET *	pstruFragmentPacketList

char	szCountryCode [4]

unsigned int	nMaxProbabilityofFalseAlarm

CPE_METRICS	struCPEMetrics

Detailed Description

CPE structure for IEEE 802.22 MAC.

Definition at line 868 of file 802_22.h.

Field Documentation

◆ BWRequestInfo

struct stru_802_22_CPE_BWRequestInfo* stru_802_22_CPE_MAC::BWRequestInfo

Definition at line 890 of file 802_22.h.

◆ nBLM_REPRetries

int stru_802_22_CPE_MAC::nBLM_REPRetries

Number of retries allowed for sending BLMREP. Default 3.

Definition at line 889 of file 802_22.h.

◆ nBSID

NETSIM_ID stru_802_22_CPE_MAC::nBSID

Definition at line 870 of file 802_22.h.

◆ nBSInterface

NETSIM_ID stru_802_22_CPE_MAC::nBSInterface

Definition at line 871 of file 802_22.h.

◆ nDSXRequestRetries

int stru_802_22_CPE_MAC::nDSXRequestRetries

3 fixed

Definition at line 875 of file 802_22.h.

◆ nDSXResponseReties

int stru_802_22_CPE_MAC::nDSXResponseReties

3 fixed

Definition at line 877 of file 802_22.h.

◆ nMaxProbabilityofFalseAlarm

unsigned int stru_802_22_CPE_MAC::nMaxProbabilityofFalseAlarm

Definition at line 896 of file 802_22.h.

◆ nSID

unsigned int stru_802_22_CPE_MAC::nSID

Unique station idetifier.

Definition at line 873 of file 802_22.h.

◆ pstruFragmentPacketList

NetSim_PACKET* stru_802_22_CPE_MAC::pstruFragmentPacketList

Definition at line 894 of file 802_22.h.

◆ pstruQueuedPacketList

NetSim_PACKET* stru_802_22_CPE_MAC::pstruQueuedPacketList[MAX_FID]

Definition at line 891 of file 802_22.h.

◆ pstruServiceParameter

CR_SERVICE* stru_802_22_CPE_MAC::pstruServiceParameter

Definition at line 892 of file 802_22.h.

◆ pstruUSBurst

NetSim_PACKET* stru_802_22_CPE_MAC::pstruUSBurst

Definition at line 893 of file 802_22.h.

◆ struCPEMetrics

CPE_METRICS stru_802_22_CPE_MAC::struCPEMetrics

Definition at line 897 of file 802_22.h.

◆ szCountryCode

char stru_802_22_CPE_MAC::szCountryCode[4]

Definition at line 895 of file 802_22.h.

◆ T14

double stru_802_22_CPE_MAC::T14

Wait for DSx-RSP/DSX-RVD Timeout. Max 200 ms.

Definition at line 883 of file 802_22.h.

◆ T16

double stru_802_22_CPE_MAC::T16

Wait for bandwidth request grant. Min 10 ms.

Definition at line 885 of file 802_22.h.

◆ T29

double stru_802_22_CPE_MAC::T29

Wait for BLM-ACK timeout. Range 10-300 ms.

Definition at line 887 of file 802_22.h.

◆ T7

double stru_802_22_CPE_MAC::T7

Wait for DSA/DSC/DSD Response timeout. Max 1 sec.

Definition at line 879 of file 802_22.h.

◆ T8

double stru_802_22_CPE_MAC::T8

Wait for DSA/DSC Acknowledge timeout. Max 300 ms.

Definition at line 881 of file 802_22.h.

The documentation for this struct was generated from the following file:

802_22.h
